The LTN series of narrow body light towers are ideally suited for illuminating general job sites, site prep, concrete pours, specialty events, paring lots road work and bridge work. A 30-foot adjustable tower rotates 360 degrees for optimum lighting flexibility. Quiet operation, the quietest in its class with sound levels as low as 67 dB(A) at 23 feet, offers maximum versatility for almost any applications. Large fuel tank allows for continuous lighting/run time.
| Operating data | ||
|---|---|---|
| Illumination coverage at 5 fc (54 lux) ft² | 12,960 | |
| Lamp type | Metal Halide | |
| Mast height ft | 30 | |
| L x W x H in | 180.4 x 59.3 x 73.2 | |
| Sound level (LwA) at 23 ft (7 m) dB(A) | 67 | |
| Power kW | 6 | |
| Frequency Hz | 60 | |
| Voltage V | 120 | |
| Power factor cos Φ 1~ | 1 | |
| Voltage control % | 6 | |
| Idle to full load % | 10 | |
| Engine / Motor | ||
|---|---|---|
| Generator insulation (class) | H | |
| RPM / speed rpm | 1,800 | |
| Generator model | Brushless | |
| Engine / Motor type | Liquid-cooled 3-cylinder diesel engine | |
| Engine / Motor manufacturer | Kohler | |
| Displacement in³ | 62.7 | |
| Operating performance hp | 13.4 | |
| at rpm rpm | 1,800 | |
| Rated performance | ISO 3,046 IFN | |
| Tank capacity US gal | 32.5 | |
| Fuel consumption US gal/h | 0.45 | |
