The Cormidi C85 is a 810 mm wide, 800kg tracked carrier, complete with a high tip height of 1.5 meters and oscillating rocking rollers providing a fast, efficient and safe way to transport dirt and other bulk materials on and off job sites. Featuring Hydrostatic Transmission, these machines are easy to use and low maintenance.
| Engine | |
|---|---|
| Engine Model | Honda Gx 390 13 hp |
| Transmission | |
|---|---|
| Type | Hydrostatic |
| Hydraulic Pump | 2 variable pistons pumps 2x variable displ. |
| Tracks | |
|---|---|
| Standard Track Width | 180 mm (7.1 in) |
| Rocking Rollers | Yes |
| Rollers | 2 |
| Hydraulic System | |
|---|---|
| Hydraulic Pump | Gear pump |
| Flow Std | 1 x 15.8 l/min | (1 x 4.2 gpm) |
| Hi-flow | 1 x 22 l/min | (1 x 5.8 gpm) |
| Max Pressure | 150 bar | (2180 psi) |
| Performance and Dimensions | |
|---|---|
| Max. Travel Speed | 6 kmh / 3.7 mph |
| Operatve weight | 800 kg (1762 LB) |
| Dry Weight | 540 to 750 kg |
| Skip capacity | 0.28 m³ to 0.45 m³ |
| Parking brake | Yes |
