The S250 is a great all-around skid-steer loader. Not only does it excel at dirt work and running attachments, but also truck loading applications because of its vertical lift path design which gives the operator more reach at full height.
S250 – Bobcat™
More Information
Call for Details.
Specifications
| Engine | |
|---|---|
| Engine Cooling | Liquid |
| Emissions Tier (EPA) | Tier 3 |
| Engine Fuel | Diesel |
| Horsepower | 75 HP |
| Turbocharged Engine | Yes |
| Performance | |
|---|---|
| Rated Operating Capacity (SAE) | 2500 lbs |
| Tipping Load | 5661 lbs |
| Operating Weight | 7825 lbs |
| Travel Speed | 6.9 mph |
| Travel Speed (2-speed option) | 12 mph |
| Capacities | |
|---|---|
| Fuel Tank | 23 gal |
| Hydraulic System | |
|---|---|
| System Relief @ Quick Couplers | 3300 psi |
| Auxiliary Std Flow | 20.7 GPM |
| Auxiliary High Flow | 37 GPM |
| Dimension | |
|---|---|
| Length | 114.5 in |
| Length without Attachment | 114.5 in |
| Length with Standard Bucket | 142.9 in |
| Width | 72 in |
| Width (with bucket) | 74 in |
| Height | 80.9 in |
| Height with Operator Cab | 80.9 in |
| Height to Bucket Hinge Pin | 128.8 in |
| Reach @ Maximum Height | 34 in |
| Turning Radius | 84.2 in |
| Wheelbase | 48.3 in |
