3947 E Compact Scissor Lift- Haulotte™

  • Exceptional productivity
  • Working height up to 44 ft 9 in
  • Driveable at full height
  • Load capacity: 770 lbs
  • Extended platform
  • Long working cycles
  • Reliable and easy to maintain
  • Optimum compactness
  • 3 ft 11 in width
  • Folding guardrails





haulotte logo

More Information

Haulotte 3947E Compact Scissor Lifts PDF

Specifications

Working height 44 ft 11 in
Platform height 38 ft 11 in
Lift capacity 770 lbs
Platform length – outside 7 ft 7 in
Platform length – extended 10 ft 7 in
Extension length 3 ft
Platform width – outside 3 ft 11 in
Storage height 6 ft 10 in
Height – stowed 8 ft 2 in
Overall width 3 ft 11 in
Length 8 ft 2 in
Wheelbase 6 ft 1 in
Ground clearance 6 in
Ground clearance – Pothole guards deployed 1 in
Drive speed 0.6 – 1.7 mph
Driveable at full height up to 38 ft 11 in
Gradeability 23 %
Tilt alarm 2° / 3°
Lift / lower speed 61 s / 50 s
Turning radius – outside 8 ft 2 in
Non-marking tires 15×5
Batteries 24 V – 340 Ah (C20)
Hydraulic system capacity 7 gal
Weight 7,236 lbs
Platform size – extended 10 ft 7 in x 3 ft 11 in
Lift capacity – inside 0 lbs
